ContX IQ: With Person node as a subject, gives a company a consent on a payment method and then revokes it.

Link a user access token with existing captured data and use this authorization to create and delete a relationship within the scope of a policy with a Person as subject.

Use case

In this case, a Person node access token is sent and introspected to create and delete a consent relationship, between a company and a payment method, linked with the Person node.

Requirements

- ServiceAccount credentials created in the IndyKite Hub for your organization.

- AppAgent credentials created in the IndyKite Hub, using the REST endpoints or using Terraform for your Project / Application.

- Access token for a Person node.

User Access tokens are sent in CIQ Execution in Headers: key:Authorization, value:Bearer token.

Steps

1. Using the AppAgent credential as API Key (name: X-IK-ClientKey), ingest data in your IKG (IndyKite Knowledge Graph) using the script provided.

2. Using the ServiceAccount credential as Bearer token, create a CIQ Policy which designates a relationship between a PaymentMethod and a Company can be upserted.

3. Using the ServiceAccount credential as Bearer token, create a CIQ Query in the context of the policy to create a GRANTED relationship between a company and a payment method.

4. Using the AppAgent credential as API Key (name: X-IK-ClientKey), run a CIQ Execution to create a GRANTED relationship between the PaymentMethod of the Person node and a Company, from the Person access token.

5. Using the ServiceAccount credential as Bearer token, create a CIQ Policy which designates a relationship between a PaymentMethod and a Company can be deleted.

6. Using the ServiceAccount credential as Bearer token, create a CIQ Query in the context of the policy to delete a GRANTED relationship between a company and a payment method.

7. Using the AppAgent credential as API Key (name: X-IK-ClientKey), run a CIQ Execution to delete a GRANTED relationship between the PaymentMethod of the Person node and a Company, from the Person access token.

Step 1

Ingest the nodes needed for this use case.

POST https://eu.api.indykite.com/capture/v1/nodes/Json

{
  "nodes": [
    {
      "external_id": "alice",
      "is_identity": true,
      "type": "Person",
      "properties": [
        {
          "type": "email",
          "value": "alice@email.com"
        },
        {
          "type": "given_name",
          "value": "Alice"
        },
        {
          "type": "last_name",
          "value": "Smith"
        }
      ]
    },
    {
      "external_id": "bob",
      "type": "Person",
      "is_identity": true,
      "properties": [
        {
          "type": "email",
          "value": "bob@email.com"
        },
        {
          "type": "given_name",
          "value": "Bob"
        }
      ]
    },
    {
      "external_id": "cb123",
      "type": "PaymentMethod",
      "properties": [
        {
          "type": "payment_name",
          "value": "Credit Card"
        }
      ]
    },
    {
      "external_id": "kl123",
      "type": "PaymentMethod",
      "properties": [
        {
          "type": "payment_name",
          "value": "Klarna"
        }
      ]
    },
    {
      "external_id": "ct123",
      "type": "Contract",
      "properties": [
        {
          "type": "category",
          "value": "Parking"
        },
        {
          "type": "status",
          "value": "Active"
        }
      ]
    },
    {
      "external_id": "ct234",
      "type": "Contract",
      "properties": [
        {
          "type": "category",
          "value": "Parking"
        },
        {
          "type": "status",
          "value": "Active"
        }
      ]
    },
    {
      "external_id": "car1",
      "type": "Vehicle",
      "properties": [
        {
          "type": "category",
          "value": "Car"
        },
        {
          "type": "is_active",
          "value": true
        },
        {
          "type": "vin",
          "value": "rtfhcnvjt471"
        }
      ]
    },
    {
      "external_id": "car2",
      "type": "Vehicle",
      "properties": [
        {
          "type": "category",
          "value": "Car"
        },
        {
          "type": "is_active",
          "value": true
        },
        {
          "type": "vin",
          "value": "kdcbfrt178"
        }
      ]
    },
    {
      "external_id": "license1",
      "type": "LicenseNumber",
      "properties": [
        {
          "type": "status",
          "value": "Active"
        },
        {
          "type": "number",
          "value": "AX123456",
          "metadata": {
            "assurance_level": 3,
            "source": "BRREG"
          }
        }
      ]
    },
    {
      "external_id": "license2",
      "type": "LicenseNumber",
      "properties": [
        {
          "type": "status",
          "value": "Active"
        },
        {
          "type": "number",
          "value": "OL123456",
          "metadata": {
            "assurance_level": 3,
            "source": "BRREG"
          }
        }
      ]
    },
    {
      "external_id": "companyParking",
      "type": "Company",
      "properties": [
        {
          "type": "name",
          "value": "City Parking Inc"
        }
      ]
    }
  ]
}

Ingest the relationships needed for this use case.

POST https://eu.api.indykite.com/capture/v1/relationships/Json

{
  "relationships": [
    {
      "source": {
        "external_id": "bob",
        "type": "Person"
      },
      "target": {
        "external_id": "kl123",
        "type": "PaymentMethod"
      },
      "type": "HAS"
    },
    {
      "source": {
        "external_id": "alice",
        "type": "Person"
      },
      "target": {
        "external_id": "cb123",
        "type": "PaymentMethod"
      },
      "type": "HAS"
    },
    {
      "source": {
        "external_id": "alice",
        "type": "Person"
      },
      "target": {
        "external_id": "ct123",
        "type": "Contract"
      },
      "type": "ACCEPTED"
    },
    {
      "source": {
        "external_id": "bob",
        "type": "Person"
      },
      "target": {
        "external_id": "ct234",
        "type": "Contract"
      },
      "type": "ACCEPTED"
    },
    {
      "source": {
        "external_id": "ct123",
        "type": "Contract"
      },
      "target": {
        "external_id": "car1",
        "type": "Vehicle"
      },
      "type": "COVERS"
    },
    {
      "source": {
        "external_id": "ct234",
        "type": "Contract"
      },
      "target": {
        "external_id": "car2",
        "type": "Vehicle"
      },
      "type": "COVERS"
    },
    {
      "source": {
        "external_id": "car1",
        "type": "Vehicle"
      },
      "target": {
        "external_id": "license1",
        "type": "LicenseNumber"
      },
      "type": "HAS"
    },
    {
      "source": {
        "external_id": "car2",
        "type": "Vehicle"
      },
      "target": {
        "external_id": "license2",
        "type": "LicenseNumber"
      },
      "type": "HAS"
    },
    {
      "source": {
        "external_id": "companyParking",
        "type": "Company"
      },
      "target": {
        "external_id": "ct234",
        "type": "Contract"
      },
      "type": "OFFERS"
    },
    {
      "source": {
        "external_id": "companyParking",
        "type": "Company"
      },
      "target": {
        "external_id": "ct123",
        "type": "Contract"
      },
      "type": "OFFERS"
    }
  ]
}

Step 2

Create a CIQ Policy which designates a relationship between a PaymentMethod and a Company can be upserted.

policy.jsonJson

{
  "meta": {
    "policy_version": "1.0-ciq"
  },
  "subject": {
    "type": "Person"
  },
  "condition": {
    "cypher": "MATCH (company:Company)-[:OFFERS]->(contract:Contract)<-[:ACCEPTED]-(subject:Person)-[:HAS]->(payment:PaymentMethod), (contract)-[:COVERS]->(vehicle:Vehicle)-[:HAS]->(ln:LicenseNumber)",
    "filter": [
      {
        "operator": "AND",
        "operands": [
          {
            "attribute": "subject.external_id",
            "operator": "=",
            "value": "$subject_external_id"
          },
          {
            "attribute": "$token.sub",
            "operator": "=",
            "value": "$token_sub"
          }
        ]
      }
    ]
  },
  "allowed_reads": {
    "nodes": [
      "company.*",
      "subject.*",
      "payment.*"
    ]
  },
  "allowed_upserts": {
    "relationships": {
      "relationship_types": [
        {
          "type": "GRANTED",
          "source_node_label": "Company",
          "target_node_label": "PaymentMethod"
        }
      ]
    }
  }
}

Request to create the CIQ Policy configuration using REST.

POST https://eu.api.indykite.com/configs/v1/authorization-policiesJson

{
  "project_id": "your_project_gid",
  "description": "description of policy",
  "display_name": "policy name",
  "name": "policy-name",
  "policy": "{\"meta\":{\"policy_version\":\"1.0-ciq\"},\"subject\":{\"type\":\"Person\"},\"condition\":{\"cypher\":\"MATCH (company:Company)-[:OFFERS]->(contract:Contract)<-[:ACCEPTED]-(subject:Person)-[:HAS]->(payment:PaymentMethod), (contract)-[:COVERS]->(vehicle:Vehicle)-[:HAS]->(ln:LicenseNumber)\",\"filter\":[{\"operator\":\"AND\",\"operands\":[{\"attribute\":\"subject.external_id\",\"operator\":\"=\",\"value\":\"$subject_external_id\"},{\"attribute\":\"$token.sub\",\"operator\":\"=\",\"value\":\"$token_sub\"}]}]},\"allowed_reads\":{\"nodes\":[\"company.*\",\"subject.*\",\"payment.*\"]},\"allowed_upserts\":{\"relationships\":{\"relationship_types\":[{\"type\":\"GRANTED\",\"source_node_label\":\"Company\",\"target_node_label\":\"PaymentMethod\"}]}}}",
  "status": "ACTIVE",
  "tags": []
}

Request to read the CIQ Policy configuration using REST.

policy_request.jsonJson

{
  "id": "your_policy_configuration_gid"
}

Step 3

Create a CIQ Query in the context of the policy to create a GRANTED relationship between a company and a payment method.

knowledge_query.jsonJson

{
  "nodes": [
    "company.external_id",
    "subject.external_id",
    "payment.external_id"
  ],
  "upsert_relationships": [
    {
      "name": "newRel",
      "source": "company",
      "target": "payment",
      "type": "GRANTED"
    }
  ]
}

Request to create a CIQ Query configuration using REST.

POST https://eu.api.indykite.com/configs/v1/knowledge-queriesJson

{
  "project_id": "your_project_gid",
  "description": "description of knowledge query",
  "display_name": "knowledge query name",
  "name": "knowledge-query-name",
  "policy_id": "your_policy_gid",
  "query": "{\"nodes\":[\"company.external_id\",\"subject.external_id\",\"payment.external_id\"],\"upsert_relationships\":[{\"name\":\"newRel\",\"source\":\"company\",\"target\":\"payment\",\"type\":\"GRANTED\"}]}",
  "status": "ACTIVE"
}

Read the CIQ Query Configuration.

GET https://eu.api.indykite.com/configs/v1/knowledge-queries/{id}Json

{
  "id": "your_knowledge_query_configuration_gid"
}

Step 4

Run a CIQ Execution to create a GRANTED relationship from the Person access token.

POST https://eu.api.indykite.com/contx-iq/v1/executeJson

{
  "id": "knowledge_query_gid",
  "input_params": {
    "subject_external_id": "alice",
    "token_sub": "alice_user_external_id"
  },
  "page_token": 1
}

CIQ Execution response.

response.jsonJson

{
  "data": [
    {
      "nodes": {
        "company.external_id": "companyParking",
        "payment.external_id": "cb123",
        "subject.external_id": "alice"
      }
    }
  ]
}

Step 5

Create a CIQ Policy which designates a relationship between a PaymentMethod and a Company can be deleted.

policy.jsonJson

{
  "meta": {
    "policy_version": "1.0-ciq"
  },
  "subject": {
    "type": "Person"
  },
  "condition": {
    "cypher": "MATCH (company:Company)-[g1:GRANTED]->(payment:PaymentMethod)<-[:HAS]-(subject:Person)",
    "filter": [
      {
        "operator": "AND",
        "operands": [
          {
            "attribute": "subject.external_id",
            "operator": "=",
            "value": "$subject_external_id"
          },
          {
            "attribute": "$token.sub",
            "operator": "=",
            "value": "$token_sub"
          }
        ]
      }
    ]
  },
  "allowed_reads": {
    "nodes": [
      "company.*",
      "subject.*",
      "payment.*"
    ]
  },
  "allowed_deletes": {
    "relationships": [
      "g1"
    ]
  }
}

Json to create the CIQ Policy configuration using REST.

POST https://eu.api.indykite.com/configs/v1/authorization-policiesJson

{
  "project_id": "your_project_gid",
  "description": "description of policy",
  "display_name": "policy name",
  "name": "policy-name",
  "policy": "{\"meta\":{\"policy_version\":\"1.0-ciq\"},\"subject\":{\"type\":\"Person\"},\"condition\":{\"cypher\":\"MATCH (company:Company)-[g1:GRANTED]->(payment:PaymentMethod)<-[:HAS]-(subject:Person)\",\"filter\":[{\"operator\":\"AND\",\"operands\":[{\"attribute\":\"subject.external_id\",\"operator\":\"=\",\"value\":\"$subject_external_id\"},{\"attribute\":\"$token.sub\",\"operator\":\"=\",\"value\":\"$token_sub\"}]}]},\"allowed_reads\":{\"nodes\":[\"company.*\",\"subject.*\",\"payment.*\"]},\"allowed_deletes\":{\"relationships\":[\"g1\"]}}",
  "status": "ACTIVE",
  "tags": []
}

Json to read the CIQ Policy configuration using REST.

policy_request.jsonJson

{
  "id": "your_policy_configuration_gid"
}

Step 6

Create a CIQ Query in the context of the policy to delete a GRANTED relationship between a company and a payment method.

knowledge_query.jsonJson

{
  "nodes": [
    "company.external_id",
    "subject.external_id",
    "payment.external_id"
  ],
  "delete_relationships": [
    "g1"
  ]
}

Json to create a CIQ Query configuration using REST.

POST https://eu.api.indykite.com/configs/v1/knowledge-queriesJson

{
  "project_id": "your_project_gid",
  "description": "description of knowledge query",
  "display_name": "knowledge query name",
  "name": "knowledge-query-name",
  "policy_id": "your_policy_gid",
  "query": "{\"nodes\":[\"company.external_id\",\"subject.external_id\",\"payment.external_id\"],\"delete_relationships\":[\"g1\"]}",
  "status": "ACTIVE"
}

Read the CIQ Query Configuration.

GET https://eu.api.indykite.com/configs/v1/knowledge-queries/{id}Json

{
  "id": "your_knowledge_query_configuration_gid"
}

Step 7

Run a CIQ Execution to delete a GRANTED relationship from the Person access token.

POST https://eu.api.indykite.com/contx-iq/v1/executeJson

{
  "id": "knowledge_query_gid",
  "input_params": {
    "subject_external_id": "alice",
    "token_sub": "alice_user_external_id"
  },
  "page_token": 1
}

CIQ Execution response.

response.jsonJson

{
  "data": [
    {
      "nodes": {
        "company.external_id": "companyParking",
        "payment.external_id": "cb123",
        "subject.external_id": "alice"
      }
    }
  ]
}
